Echo CS-2511T Owner's/Operator's Manual

34
CS-2511T
* Technical data subject to change without notice.
TECHNICAL DATA
MODEL CS-2511T
Dimension L × W × H mm (in) 243 × 205 × 196 (9.57 × 8.07 × 7.72 )
Mass Power head, dry kg (lb) 2.3 (5.07) Without chain and guide bar
Engine Type Air-cooled two-stroke single cylinder
Displacement mL (in³) 25.0 (1.53)
Carburetor Diaphragm type
Magneto Flywheel magneto: CDI system
Spark plug NGK CMR7H
Starter Recoil starter
Power transmission Automatic centrifugal clutch
Fuel Mixture ratio 50:1 ratio with ECHO Power Blend X™ or ECHO
Red Armor® ISO-L-EGD (ISO/CD 13738) and JASO
M345-FD two-stroke, air-cooled engine oil.
Gasoline Use 89 octane unleaded.
Do not use fuel containing methyl alcohol, more than
10 % ethyl alcohol or 15 % MTBE.
Do not use alternative fuels such as E-15 or E-85.
Tank capacity L ( oz) 0.190 (6.42)
Oil Bar and chain ECHO bar and chain oil
Tank capacity L ( oz) 0.140 (4.73)
Guide bar and
saw chain
See page 23 for Chain and Guide Bar Combination
Lubrication Adjustable automatic oil pump
Engine speed Idle
RPM
2,800 - 3,600
Clutch engagement 4,100 - 4,600
Wide open throttle 12,200 - 13,400
Standard
features
Front hand guard, Anti-vibration device,
Throttle control lockout, Chain brake, Chain catcher,
Spark arrestor muer, (Kick guard),
(Spiked bumper; option)
WARNING
Do not store in an enclosure where fuel
fumes may accumlate or reach an open ame
or spark.
CAUTION
Do not lend or rent your chain saw without
the operators manual and Safety manual.
NOTICE
• For future reference, you should keep this
operators manual and the Safety manual.
• If this operators manual or the Safety manual
has become illegible or is lost, please purchase
a new one from your ECHO dealer.
STORAGE AFTER USE
• Inspect and adjust every part of the chain saw.
- Completely clean every part and repair if
necessary.
- Apply thin coating of oil on metal parts to
prevent rust.
• Remove chain and guide bar.
• Drain fuel tank, pull starter slowly a few times
to drain fuel from carburetor.
• Pour a small amount of clean motor oil into
spark plug hole, pull starter and crank the
engine until piston reaches: TOP DEAD CEN-
TER.
• Store in a dry area, free from dust.

Echo CS-2511T Specifications

General

Engine Displacement	25.0 cc
Fuel Tank Capacity	190 ml
Oil Tank Capacity	140 ml
Weight (without bar and chain)	2.3 kg
Chain Pitch	3/8 in
Chain Gauge	0.050 in
Bar Length	12 in
Fuel Capacity	190 ml
Oil Capacity	140 ml
Guide Bar Length	12 in
