Echo CS-2511T Owner's/Operator's Manual

25
CS-2511T
CHAIN AND GUIDE BAR COMBINATION
The following combinations are recommended for model CS-2511T.
GUIDE BAR
(Low-kickback)
Replacement guide bars.
The following guide bars may be considered to
have equivalent kickback energy.
• Sprocket nose guide bars of the same length
and nose radius, same pitch and having the
same number of teeth.
• Hard nose guide bars of the same length and
nose radius as a sprocket nose bar.
SAW CHAIN
(Low-kickback)
WARNING
Do not use replacement saw chain unless
it has been designated as meeting the ANSI
B175.1 or CSA Z62.3 kickback performance
requirements, when tested on the
representative sample of chain saws below
3.8 c.i.d. specied in ANSI B175.1 and CSA
Z62.3.
NOTICE
LOW KICKBACK SAW CHAIN meets the
kickback performance requirements of ANSI
B175.1 or CSA Z62.3 (safety requirements for
gasoline-powered chain saws).
Guide bar Saw chain
Length mm (in.)
ECHO Part No.
Pitch mm (in.) ECHO Part No. Links
Double Guard
305 (12)
12A0CD3745
9.53 (3/8)
91PXL45CQ
45
12A4CD3745 90PX45CQ
356 (14)
14A0CD3752 91PXL52CQ
52
14A4CD3752 90PX52CQ

Echo CS-2511T Specifications

General

Engine Displacement	25.0 cc
Fuel Tank Capacity	190 ml
Oil Tank Capacity	140 ml
Weight (without bar and chain)	2.3 kg
Chain Pitch	3/8 in
Chain Gauge	0.050 in
Bar Length	12 in
Fuel Capacity	190 ml
Oil Capacity	140 ml
Guide Bar Length	12 in
