Echo CS-303T User Manual

OPERATION CS-303T
38 X7503209108
© 10/20 ECHO Incorporated
Checking Chain Tension
Do not operate with a loose chain. Serious injury can occur.
Chain tension should be checked
frequently during work and corrected
as necessary.
Chain Lubrication Test
Hold the chain just above a dry
surface and open the throttle to half
speed for 30 seconds.
A thin line of “thrown” oil should be
seen on the dry surface.
Cutting Instructions
General
◆ This chain saw is designed for cutting wood. Do not cut
metal, plastic or any non-wood material.
◆ Wear suitable hearing
protection such as
earmuffs or earplugs to
protect against
objectionable or
uncomfortable loud
noises.

Echo CS-303T Specifications

General

Engine Displacement	30.1 cc
Fuel Capacity	0.21 US quarts
Oil Capacity	0.16 US quarts
Guide Bar Length	12 inches
Power Source	Gas
Fuel Tank Capacity	260 ml
Oil Tank Capacity	0.16 US quarts
Weight (without bar and chain)	3.9 kg
Chain Pitch	3/8 in.
Chain Gauge	0.050 in.
