Echo CS-303T User Manual

OPERATION CS-303T
30 X7503209108
© 10/20 ECHO Incorporated
Starting Cold Engine
Make sure the bar and chain are free from any obstruction when
starting the chain saw.
1. Move chain brake lever fully
FORWARD to LOCK chain
brake before starting.
2. Fill the fuel tank with fuel
mixture. Do not over fill.
3. Fill the chain oil tank with
lubricant. Do not over fill.
4. Move Stop Switch (A)
FORWARD to “RUN” position.
5. Push Purge Pump (B) 8 times.
6. Pull Choke Control Knob (C) all
the way out. (Choke position
(CLOSED [ ] choke position).
A
B
B
C

Echo CS-303T Specifications

General

Engine Displacement	30.1 cc
Fuel Capacity	0.21 US quarts
Oil Capacity	0.16 US quarts
Guide Bar Length	12 inches
Power Source	Gas
Fuel Tank Capacity	260 ml
Oil Tank Capacity	0.16 US quarts
Weight (without bar and chain)	3.9 kg
Chain Pitch	3/8 in.
Chain Gauge	0.050 in.
