CS-303T OPERATION
X7503209108 43
© 10/20 ECHO Incorporated
Chain And Guide Bar Combination
The following combinations are recommended for model CS-303T.
Use of replacement saw chain and/or guide bar other than that
specified, or operation without the optional Kick Guard
TM
in
place, may cause severe kickback resulting in serious injury.
Chain and guide bar gauge size must be identical. Use Bar/Chain
combinations shown in table above.
Kick Guard
TM
(Optional)
To purchase an optional Kick Guard
TM
contact your ECHO dealer. For the
name of the ECHO dealer nearest you, Call: 1-800-432-ECHO (3246) or on
the web at www.echo-usa.com
Guide Bar
(Low-kickback)
Replacement guide bars.
The following guide bars may be considered to have equivalent kickback
energy.
• Sprocket nose guide bars of the same length and nose radius, same pitch
and having the same number of teeth.
• Hard nose guide bars of the same length and nose radius as a sprocket
nose bar.
Low Kickback Guide Bar Low Kickback Saw Chain
Kick
Guard
TM
Length Bar P/N Chain P/N Links Type Pitch Gauge
Echo P/N
(OEM P/N)
12” 12A0CD3745
91PX45CQ
91VG45CQ
45
91PX
91VG
3/8” 0.050
2894901
28949
14” 14A0CD3752
91PX52CQ
91VG52CQ
52

Echo CS-303T Specifications

General

Engine Displacement	30.1 cc
Fuel Capacity	0.21 US quarts
Oil Capacity	0.16 US quarts
Guide Bar Length	12 inches
Power Source	Gas
Fuel Tank Capacity	260 ml
Oil Tank Capacity	0.16 US quarts
Weight (without bar and chain)	3.9 kg
Chain Pitch	3/8 in.
Chain Gauge	0.050 in.
