CS-310 MAINTENANCE
X7503275401 45
© 02/2019 ECHO Inc.
Spark Plug
Check periodically.
The standard spark gap is 0.65
mm (0.026 in.).
Fastening torque: 13-17 N•m
(110-150 in•lbf).
1. Remove cylinder cover and
remove spark plug.
2. Correct the spark gap if it is wider or narrower than the standard gap.
Check Fuel System
Check before every use.
After refueling, make sure fuel does not leak from around fuel pipe, fuel
grommet or fuel tank cap.
In case of fuel leakage there is a danger of fire. Stop using the machine
immediately and request your dealer to inspect or replace.
Fuel Filter
Check periodically.
Do not allow dust to enter fuel tank.
A clogged filter (A) will cause
difficulty in starting engine or
abnormalities in engine
performance.
1. Pull filter out through gas port,
and inspect filter.
2. When the filter is dirty, replace it.
Do not damage fuel line while removing fuel filter from tank.
3. When the inside of the fuel tank is dirty, rinse the tank out with gasoline
to clean it.
0.65 mm (0.026 in.)
A

Other manuals for Echo CS-310

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Echo CS-310 and is the answer not in the manual?

Echo CS-310 Specifications

General IconGeneral
Engine Displacement30.5 cc
Bar Length14 inches
Weight8.8 lbs
Chain Pitch3/8 inch
Chain Gauge0.050 inch
