CS-350WES
14
IGNITION SYSTEM
3 IGNITION SYSTEM
( A ) Ignition switch
( B ) Stop lead
( C ) Spark plug
( D ) Spark plug cap coil
( E ) Spark plug cap
( F ) High tension lead
(G) Ignition coil
( H ) Flywheel
( J ) Ground lead
( K ) Ground lead
( L ) Spacer
(H)
(C)
(D)
(E)
(F)
(B)
(G)
(A)
(K)
(J)
(L)
