Echo CS-350WES Service Manual

CS-350WES
64
MAINTENANCE GUIDE
11 MAINTENANCE GUIDE
11-1 Disassembly Chart
A
A
Muffler
cover
Spark plug
(3-3,3-8)
Air cleaner
lid
(4-1)
Starter
assembly
(2-1)
Front
handle
(9-1)
Air filter
(4-1)
Ignition
switch
(3-5)
Front side
cushion
(9-1,2)
Flywheel
(3-11)
Ignition
coil
(3-6)
Rear
handle
(9-3)
Carburetor
(4-7)
Throttle
trigger
(9-4)
Throttle
rod
(9-4)
Cushions
(9-3)
Rear
handle
(9-3,5)
Intake
bellows
(4-13,9-5)
Engine
cover
(7-12)
Crankcase
(4-13,7-8)
Starter side
ball bearing
(7-9)
Starter side
oil seal
(7-9)
Piston
Crankshaft
assembly
(7-8)
Clutch side
ball bearing
(5-1)
Clutch side
oil seal
(5-1)
Cylinder
piston ring
(7-7)
Exhaust
Muffler
(7-2)
Auto-oiler
(6-5)
Clutch
drum
(5-1)
Clutch
assembly
(5-1)
Guide bar
cover
(10-1)
Worm
gear
(6-6)
