Echo CS-355T Service Manual

2
SERVICE INFORMATION
CS-355T
1 SERVICE INFORMATION
1-1 Specifications
Model
CS-355T
Dimensions
Length*
mm(in)
287 (11.30)
Width mm(in)
244 (9.61)
Height mm(in)
220 (8.66)
Dry weight*
kg(lb)
3.5 (7.7)
Engine Type YAMABIKO, air-cooled, two-stroke, single cylinder
Rotation Clockwise as viewed from the output end
Displacement cm
3
(in
3
) 35.8 (2.184)
Bore mm(in) 39.0 (1.535)
Stroke mm(in) 30.0 (1.181)
Compression ratio 7.1
Diaphragm horizontal-draught
Carburetor Type
with separated purge bulb
Model
WALBRO WT-1049
Venturi size-Throttle bore mm(in) 13.5 - 15.85 (0.531 - 0.624)
Ignition Type CDI (Capacitor discharge ignition) system
Digital Magneto with stop holding function
Spark plug BPM8Y (CANADA : BPMR8Y)
Starter Type i-15
Rope diameter x length mm(in) 3.0 x 950 (0.12 x 36.2)
Fuel Type Premixed two-stroke fuel
Mixture ratio 50 : 1 (2 %)
Petrol Minimum 89 octane petrol
Two-stroke air cooled engine oi
l
ISO-L-EGD (ISO/CD13738), JASO M345-FC/FD
Tank capacity L (U.S.fl.oz.) 0.33 (11.2)
Exhaust
Muffler type
Spark arrester muffler
Clutch Type
Centrifugal, 3-shoe slide with 3-tension spring
Guide bar / Saw chain lubrication type Adjustable automatic oil pump
Oil Tank capacity L (U.S.fl.oz.) 0.243 (8.2)
Auto oiler
Type
Clutch related type
Sprocket Type
Spur
Number of teeth
6
Pitch
in
3/8
* Without guide bar and saw chain.
Cutting devices
Guide bar
Part No.
14A0ED3752
16A0ED3757
Called length in 14 16
Gauge in
0.050
Saw chain
Type Oregon 91PX
Number of drive links
52
57
Pitch in
3/8
Gauge in
0.050
