OPERATION CS-4510
38 X7503350603
© 06/2019 ECHO Incorporated.
Chain And Guide Bar Combination
The following combinations are recommended for model CS-4510.
Use of replacement saw chain and/or guide bar other than that
specified, or operation without the tip guard in place, may cause
severe kickback resulting in serious injury.
Only use saw chain designated as, “LOW-KICKBACK,” that
meets ANSI B175.1 or CSA Z62.1, .3 Standard when tested on
the representative sample of chain saws below 3.8 C.I.D., and
Echo guide bar specified.
Chain and guide bar gauge size must be identical. Use Bar/Chain
combinations shown in table above.
If your tip guard is damaged or lost, contact your Echo dealer for a
replacement. For the name of the Echo dealer nearest you, Call: 1-
800-432-ECHO (3246) or on the web at www.echo-usa.com
.
Guide Bar
(Low-kickback)
Replacement guide bars.
The following guide bars may be considered to have equivalent kickback
energy.
• Sprocket nose guide bars of the same length and nose radius, same pitch
and having the same number of teeth.
Guide Bar Saw Chain
Length mm
(in.)
ECHO Part No.
Pitch mm (in.) Type Links
Low-kickback
406 (16) 16B0AD3366 9.53 (3/8) 91PX / 91VG 52
457 (18) 18B0AD3372 9.53 (3/8) 91PX / 91VG 57
508 (20) 20B0AD3378 9.53 (3/8) 91PX / 91VG 62
Optional Kick Guard
TM
P/N X1403190050
