Echo CS-800P Operator's Manual

23
CS-800P
CHAIN AND GUIDE BAR COMBINATION
The following combinations are recommended for model
cS-800P
.
GUIDE BAR
Replacement guide bars.
The following guide bars may be considered to
have equivalent kickback energy.
• Sprocketnoseguidebarsofthesamelength
and nose radius, same pitch and having the
same number of teeth.
• Hardnoseguidebarsofthesamelengthand
nose radius as a sprocket nose bar.
SAW CHAIN
CAUTION
Do not use replacement saw chain unless it
has been designated as meeting the CSA Z
62.3 kickback performance requirements.
NOTICE
LOW KICKBACK SAW CHAIN meets the
kickback performance requirements of CSA Z
62.3 (safety requirements for gasoline-powered
chain saws).
Guide bar Saw chain
Length mm (in.)
ECHO Part No.
Pitch mm (in.) ECHO Part No. Links
Symmetrical
508 (20) 20D0PS3870
9.53 (3/8)
72LPX70CQ 70
610 (24) 24D0PS3881 72LPX81CQ 81
686 (27) 27D0PS3893 72LPX93CQ 93
813 (32) 32D0PS3805 72LPX105CQ 105
914 (36) 36D0PS3816 72LPX116CQ 116
