G
RASS
T
RIMMER
O
PERATOR
'
S
M
ANUAL
27
2. Use one piece of new nylon line 6 m (20 ft.) long and thread
through the molded loop on the spool. Pull line tight and adjust so
one end is 15 cm (6 in.) longer than the other.
3. Hold spool with words “THIS SIDE UP” facing you. Place index
finger between the strands and wind line clockwise (follow direc-
tion of arrow molded in spool), tightly and evenly.
4. Place ends of line in the two notches molded in the spool with 12.5
to 15.2 cm (5 to 6 in.) protruding.
5. Feed ends of line out housing eyelets and place spool over spring.
Be sure spool is installed correctly with the words "THIS SIDE UP."
6. Align arrows, and push down on cover and twist cover clockwise
until tab locks cover in place.
7. Pull both lines out and trim to cut-off knife length.
Before installing, test head. Push center button while pulling on
both lines. Trimmer line should advance approximately 1 (one)
inch.
