22
operation
APPLICATION RANGE
When using the generator, make sure the total load is within rated output
of a generator. Otherwise, generator damage may occur.
AC
Power
Factor
1 0.8-0.95 0.4-0.75
(Efficiency
0.85)
IG3500E ~3,000W ~2,400W ~1,200W Rated
voltage 12V
Rated
current 8A
TIP:
• Application wattage indicates when each device is used by itself.
• The simultaneous usage of AC and DC power is possible but total
wattage should not exceed the rated output.
EX:
Generator rated output 3,000V A
Frequency Power factor
AC 1.0 ~3,000W
0.8 ~2,400W
DC --- 96W (12V/8A)
