Echo IG3500E User Manual

32
parameters
Parameters
Item IG3500E Generator
Generator
Type Inverter
Rated frequency (Hz)* 60
Rated voltage (v)* 120
Rated output power (kW) 3.0
Max output power (kW) 3.3
Power Factor 1
AC output quality ISO8528 G2
THD/% <5
Noise Level dB/LpA/
LwA/K 4m (1/4 load)
60
DC Output/ V-A 12-8
Overload
Protect
DC
Non-fuse Protector
AC
Control by inverter overload
protect program
Engine
Engine Powerease
Engine type
Single cylinder, 4-stroke,
forced air cooling, OHV
Displacement (cc) 212
Fuel type Unleaded Gasoline
Fuel tank capacity (L) 10
Continue Running Time (at
rated power)(h)
5.5
Oil Tank Capacity (L) 0.6
Spark Model No.
BPR6ES/BP6ES(NGK)
F7RTC/F7TC
Starting mode Recoil Start/Electric Start
Generator
set
Length x Width x Height
(mm)
578 × 440 × 510
Net weight (kg) 45

Echo IG3500E Specifications

General

Brand	Echo
Model	IG3500E
Category	Portable Generator
Language	English
