Echo PB-2620 User Manual

PB-2620 SPECIFICATIONS
X7501190602 37
© 10/2017 ECHO Inc.
SPECIFICATIONS
MODEL PB-2620
Length
324 mm (12.8 in.) (without blower pipes)
975mm (38.3 in.) (with blower pipes)
Width 282 mm (11.1 in.)
Height 355 mm (14.0 in.)
Weight (dry)
4 kg (8.8 lb.) (without blower pipes)
4.4 kg (9.8 lb.) (with blower pipes)
Engine Type
Air cooled, two-stroke, single cylinder gasoline
engine
Bore 34.0 mm (1.34 in.)
Stroke 28.0 mm (1.1 in.)
Displacement 25.4 cm3 (1.55 in.3)
Exhaust
Spark arrestor muffler or spark arrestor muffler with
catalyst
Carburetor Diaphragm with purge pump
Ignition System Flywheel magneto, capacitor discharge ignition type
Spark Plug NGK BPMR8Y - Gap 0.65 mm (0.026 in.)
Fuel Mixed (Gasoline and Two-stroke Oil)
Gasoline / Oil Ratio 50:1
Gasoline
Use 89 Octane unleaded. Do not use fuel containing
methyl alcohol, more than 10% ethyl alcohol or 15%
MTBE. Do not use alternative fuels such as E-15 or
E-85.
Oil
ISO-L-EGD (ISO/CD 13738) and J.A.S.O. M345-
FD, two-stroke, air-cooled engine oil.
Fuel Tank Capacity 0.6L(20.3 US fl. oz.)
Starter System Automatic Recoil Starter, centrifugal type
Idle Speed 3000 RPM
Wide Open Throttle Speed
(W.O.T.)
7500 RPM
Maximum Air Speed with
round pipe (MPH)
76.7 m/sec (172 mph)
Air Volume with round pipe 12.9 m
3
/min. (456 ft.
3
/min.)
Maximum Air Speed with flat
pipe (MPH)
80.5 m/sec (180 mph)
Air Volume with flat pipe 12.1 m
3
/min. (428 ft.
3
/min.)

Echo PB-2620 Specifications

General

Engine Displacement	25.4 cc
Air Speed	172 MPH
Fuel Capacity	20.3 fl. oz.
Type	Handheld
Engine Type	2-stroke
