SPECIFICATIONS PB-755S H/T
40 X7531125705
© 11/19 ECHO Incorporated
SPECIFICATIONS
MODEL PB-755S H PB755S T
Length 380 mm (14.96 in.) 380 mm (14.96 in.)
Width 500 mm (19.69 in.) 480 mm (18.90 in.)
Height 525 mm (20.67 in.) 525 mm (20.67 in.)
Weight (dry) 11.5 kg (25.35 lb.) 11.4 kg (25.13 lb.)
Engine Type Air cooled, two-stroke, single cylinder gasoline engine
Bore 48.0 mm (1.89 in.)
Stroke 35.0 mm (1.38 in.)
Displacement 63.3 cc (3.86 cu. in.)
Exhaust
Spark arrestor muffler or spark arrestor muffler with
catalyst
Carburetor Diaphragm w/purge pump
Ignition System Flywheel magneto, capacitor discharge ignition type
Spark Plug NGK BPM-8Y (Gap 0.65 mm (0.026 in.)
Fuel Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio 50:1
Gasoline
Use 89 Octane unleaded. Do not use fuel containing
methyl alcohol, more than 10% ethyl alcohol or 15%
MTBE. Do not use alternative fuels such as E-15 or E-
85.
Oil
ISO-L-EGD (ISO/CD 13738) and J.A.S.O. M345- FD
,
two-stroke, air-cooled engine oil.
Fuel Tank Capacity 2.0 lit. (67.7 US fl. oz.)
Starter System Automatic Recoil Starter, centrifugal type
Idle Speed 3,000 RPM
Wide Open Throttle Speed
(W.O.T.)
7,050 RPM
Average Air Speed w/pipes 87.17 m/sec (195 mph)
Maximum Air Speed w/pipes 104.20 m/sec (233 mph)
Air Volume 18.50 m3/min. (653 cu. ft./min.)
Sound Level at 50 ft. dB(A)
scale per ANSI B175.2
74 dB(A)
