PB-8010 H/T SPECIFICATIONS
X7501200001 47
© 11/2018 ECHO Inc.
SPECIFICATIONS
MODEL PB-8010 H PB-8010 T
Length (with pipes) 1503 mm (59.2 in.)
Width (with pipes) 624 mm (24.6 in.) 597 mm (23.5 in.)
Height (with pipes) 544 mm (21.4 in.)
Weight (full tank) (w th pipes) 13.1 kg (28.8 lb.) 13 kg (28.6 lb.)
Engine Type
Air cooled, two-stroke, single cylinder gasoline
engine
Bore 53 mm (2.1 in.)
Stroke 36.2 mm (1.4 in.)
Displacement 79.9 cc (4.9 cu
3
)
Exhaust
Spark arrestor muffler or spark arrestor muffler with
catalyst
Carburetor Diaphragm with purge pump
Ignition System Flywheel magneto, capacitor discharge ignition type
Spark Plug NGK CMR7H – Gap 0.65 mm (0.026 in.)
Fuel Mixed (Gasoline and Two-stroke Oil)
Gasoline/Oil Ratio 50:1
Gasoline
Use 89 Octane unleaded. Do not use fuel containing
methyl alcohol, more than 10% ethyl alcohol or 15%
MTBE. Do not use alternative fuels such as E-15 or
E-85.
Oil
ISO-L-EGD (ISO/CD 13738) and J.A.S.O. M345-
FD
, two-stroke, air-cooled engine oil.
Fuel Tank Capacity 2.48 L (83.8 US fl. oz.)
Starter System Automatic Recoil Starter, centrifugal type
Idle Speed 2,500 RPM
Wide Open Throttle Speed 7,800 RPM
Maximum Air Speed with
pipes
94.5 m/sec (211 mph)
Air Volume 30.3 m
3
/min. (1071 ft.
3
/min.)
Sound Level at 15.25 m
(50 ft.) dB(A) scale per ANSI
B175.2
79.3 dB(A)
