OPERATION PPT-2620 / H
22 X7502346700
© 11/23 ECHO Incorporated
7. Keep chain properly tensioned
at all times.
(A) - Correct cold tension. The
side link contacts the guide bar.
(B) - Chain needs tensioning.
(C) - Correct warm tension. A
distance of 1/8 in. (3 mm)
between side link and guide bar
at bottom
Note: All chains require
frequent adjustment.
8. Connect spark plug lead.
OPERATION
Moving parts can amputate fingers or cause severe injuries.
Keep hands, clothing and loose objects away from all openings.
Always stop engine, disconnect spark plug, and make sure all
moving parts have come to a complete stop before removing
obstructions, clearing debris, or servicing unit.
Engine exhaust IS HOT, and contains Carbon Monoxide (CO), a
poison gas. Breathing CO can cause unconsciousness, serious
injury, or death. Exhaust can cause serious burns. ALWAYS
position unit so that exhaust is directed away from your face
and body.
