10
Tools Required: Screwdriver.
Parts Required: Barrier Bar
Handle Adjustment
NOTE
Label shows minimum spacing for front handle location.
1. Stand in a comfortable operating position with attachment assem-
bled, and position front handle for comfortable operation. Tighten
handle screws.
Barrier Bar Assembly
NOTE
The barrier bar may be used with the PAS attachments indicated in
the barrier bar table.
1. Unscrew bottom bracket of handle, and replace with Barrier Bar as
shown. Adjust handle and secure as described above.
f r o n t h a n d l e a d j u s t m e n t /b a r r I e r b a r a s s e m b l y
mIn
spacInG
