CONTENTS
The ECHO product you purchased has been factory pre-assembled for your
convenience. Due to packaging restrictions, some assembly may be
necessary.
After opening the carton, check for damage. Immediately notify your retailer
or ECHO Dealer of damaged or missing parts. Use the contents list to check
for missing parts.
____ 1 - Brush and Gear Housing Assembly
____ 1 - Lower Driveshaft Assembly
____ 1 - Operator’s Manual
____ 1 - Storage Hook Assembly
ASSEMBLY
Gear Housing to Lower Drive Shaft Assembly
Do not perform maintenance or assembly procedures with
engine running.
1. Remove vinyl caps from attachment drive shaft.
2. Place brush gear housing assembly on a flat surface with gear housing
shaft mount at 45° angle.
Parts Required: ProSweep Gear Housing, Lower Drive Shaft
Assembly, PAS or SRM-SB Power Head (with shaft
and coupling)
