99944200553 STORAGE
X7702093407 21
© 1/2017 ECHO Inc.
ENGLISH
2. Hold 8 mm nut (B) from turning
with open end wrench inserted
through drum holder cap.
Loosen and remove bolt and
lock nut with cross head
screwdriver through holder
access hole (A).
3. Remove drum cap (C). Slide
brush holder drum off square
axle shaft.
4. Install new brush holder drum,
aligning hole (A) in drum axle
with axle shaft hole.
5. Install drum cap, aligning cap
holes with axle shaft and brush
holder drum holes.
6. Install bolt and locknut. Tighten
securely.
STORAGE
Do not immerse this attachment in water. Water will enter gear housing and
damage gears, bearings and seals.
1. Clean ProSweep attachment bristles with water.
2. Apply thin coating of oil to metal
parts to prevent rust.
3. Lubricate lower shaft assembly
with grease. (Refer to
Lubrication instructions).
