OPERATION SRM-2120
26 X7507821400
© 10/24 ECHO Incorporated
2. Choke
Move choke lever (B) to COLD
START ( ) position.
3. Purge Bulb
Pump purge bulb (C) until fuel is
visible and flows freely in the
clear fuel tank return line. Pump
bulb an additional four or five
times.
4. Recoil Starter
Lay the unit on a flat area and
keep movable attachment parts
clear of all obstacles. Firmly
grasp throttle handle and throttle
trigger lockout with left hand and
fully depress throttle trigger to
wide open position. Rapidly pull
recoil starter handle/rope (D) until engine fires (or maximum two to three
pulls).
5. Choke
After engine fires (or two to three pulls), move choke (B) to the RUN ( )
(open) position. Firmly grasp throttle handle and throttle trigger lockout
with left hand and fully depress throttle trigger to wide open position. Pull
starter handle/rope until engine starts and runs. Release throttle trigger
and allow unit to warm up at idle for several minutes.
Note: If engine does not start with choke in “RUN” position after two
to three
pulls, repeat instructions 2 - 5.
6. Throttle Trigger
After engine warm-up, grip throttle handle and support handle. Depress
the throttle trigger lockout, and gradually depress throttle trigger to
increase engine RPM to operating speed.
