MAINTENANCE SRM-2120
36 X7507821400
© 10/24 ECHO Incorporated
Fuel Filter
Level 1.
Parts required: Tune-up kit.
Fuel is flammable. Use extreme care when mixing, storing or
handling, or serious personal injury may result.
1. Use a clean cloth to remove loose dirt from around fuel cap and empty
fuel tank.
Do not damage fuel line while removing fuel filter from tank or line.
2. Pull the fuel filter from the tank.
3. Do not remove the wire coil
clamp to remove the fuel filter.
Pinch the fuel filter with the
fingers on one hand and the
fuel line with the other hand.
Pull and twist slightly to
separate.
4. Install the new filter with the
reverse action.
Note: Federal EPA regulations require all model year 2012 and
later gasoline powered engines produced for sale in the
United States to be equipped with a special low permeation
fuel supply hose between the carburetor and fuel tank. When
servicing model year 2012 and later equipment, only fuel
supply hoses certified by EPA can be used to replace the
original equipment supply hose. Fines up to $37,500 may be
enforced for using a non-certified replacement part.
