Page #11 background imageLoading...
Page #11 background image
REMARKSDESCRIPTIONQTYPART NUMBERITEM
INCLUDES ITEMS 2-4STARTER PAWL ASY1A0520000301
E-RING 42900700000042
SPRING, RETURN2177234406303
PAWL, STARTER2177218406304
NUT 81900502000085
INCLUDES ITEMS 7-13STARTER ASY1177200559316
SCREW1177236443307
DRUM, STARTER1177215406308
REPOWER BULK OPTION: 99944445000ROPE, STARTER - 3X850mm1177226039309
GUIDE, ROPE11772274203010
GRIP, STARTER11772282703011
SPRING, REWIND11772204063012
NUT19005650000513
BOLT 4X124911260401214
99922204021 - 11 - REVISED 10/11/07
Table of Contents Part Number Index
SRM-230 Trimmer Starter -- Standard
