Echo SRM-230

REMARKSDESCRIPTIONQTYPART NUMBERITEM
INCLUDES ITEMS 2-4CONTROL HANDLE KIT1178003521301
SCREW 5X351900242050352
SCREW 5X251900242050253
NUT 52900500000054
INCLUDES ITEM 6BAND ASY1301200294305
SCREW 5X141900242050146
TRIGGER, THROTTLE1178010521307
CABLE, THROTTLE1V4300007308
TUBE - 7X200mm1V4750008509
SPRING, THROTTLE RETURN11780434223010
LOCKOUT, THROTTLE11780125273011
LEVER, THROTTLE LOCKOUT11780905263212
SPRING, THROTTLE LOCKOUT11780135263013
INCLUDES ITEMS 15-17IGNITION SWITCH ASY1A44000028014
SCREW 3X101915450301015
KNOB, SWITCH11634104923116
LABEL, SWITCH18901571233017
GRIP, HANDLE13512135213018
INCLUDES ITEMS 20-21CLAMP KIT16102725213019
SCREW 5X2819002420502820
NUT 519005000000521
99922204021 - 31 - REVISED 10/11/07
Table of Contents Part Number Index
SRM-230 Trimmer Control Handle,Throttle Cable, Ignition Switch
