Echo SRM-230 Parts Catalog

REMARKSDESCRIPTIONQTYPART NUMBERITEM
STAND1305110577321
SCREW 5X222900162050222
SCREW 5X201900244050203
INCLUDES ITEM 5TANK, FUEL1A3500006604
SPACER2131045282305
WASHER 52900603000056
SCREW 5X162900162050167
VENT ASY1A3560000308
CLIP2132013266309
REPOWER BULK OPTION: 90015PIPE, VENT - 3X6X115mm1V47100011010
REPOWER BULK OPTION: 90015PIPE, RETURN - 3X6X80mm11320125603011
REPOWER BULK OPTION: 90015PIPE, FUEL - 3X6X170mm11320105203012
GROMMET, FUEL11321155593013
FILTER, FUEL
1
11312051983014
INCLUDES ITEM 16-17FUEL TANK CAP ASY11310045553015
GASKET, FUEL CAP11310165583016
CONNECTOR, FUEL CAP11310515603017
Footnotes
1: Also Included In REPOWER TUNE-UP KIT
99922204021 - 7 - REVISED 10/11/07
Table of Contents Part Number Index
SRM-230 Trimmer Fuel System

Echo SRM-230 Specifications

General

Engine Displacement	21.2 cc
Shaft Type	Straight
Engine Type	2-stroke
Carburetor	Diaphragm
Starter System	i-30™
Fuel Capacity	14.9 fl. oz.
Fuel Tank Capacity	14.9 fl. oz.
Dry Weight	12.1 lbs (5.5 kg)
