SRM-2620U DESCRIPTION
X7502341900 17
© 10/2016 ECHO Inc.
ENGLISH
14. ARM REST - Provides arm rest during operation and protects arm from
the hot engine.
15. RECOIL STARTER HANDLE - Pull handle slowly until starter engages,
then quickly and firmly. When engine starts, return handle slowly. DO
NOT let handle snap back or damage to unit will occur.
16. SPARK ARRESTOR MUFFLER OR SPARK ARRESTOR MUFFLER
WITH CATALYST - The muffler or catalytic muffler controls exhaust
noise and emission. The spark arrestor screen prevents hot, glowing
particles of carbon from leaving the muffler. Keep exhaust area clear of
flammable debris.
17. FUEL TANK - Contains fuel and fuel filter.
18. FUEL TANK CAP - Covers and seals fuel tank opening.
19. CHOKE - The choke control is located at the rear of the air cleaner
housing. Move choke lever to COLD START ( ) to close choke for
cold start. Move choke lever to RUN ( ) position to open choke.
20. AIR CLEANER - Contains replaceable filter element.
21. PURGE BULB - Pumping purge bulb before starting engine draws
fresh fuel from the fuel tank, purging air from the carburetor. Pump
purge bulb until fuel is visible and flows freely in the clear fuel tank
return line. Pump purge bulb an additional 4 or 5 times.
22. THROTTLE HANDLE - FOR RIGHT HAND - Contains Stop
Switch, Throttle Lockout, and Throttle Trigger.
23. SUPPORT HANDLE - FOR LEFT HAND.
