SERVICE INFORMATION
SRM-265ES
4
1-3 Torque limits
Descriptions Size kgf• cm N•m in•lbf
Starter Starter pawl assembly M 8 160 - 200 16 - 20 140 - 175
system
Starter case M 4* 25 - 35 2.5 - 3.5 22 - 33
Ignition Flywheel M 8 160 - 200 16 - 20 140 - 175
system
Ignition coil M 4* 35 - 50 3.5 - 5 30 - 45
Fan cover M 5* 35 - 50 3.5 - 5 30 - 45
Spark plug M 14 130 - 170 13 - 17 112 - 150
Fuel Carburettor M 5 30 - 45 3.0 - 4.5 25 - 40
system
Intake insulator M 5 60 - 80 6 - 8 55 - 70
Fuel tank with stand M 5* 40 - 60 4 - 6 32 - 55
Clutch Clutch shoe M 6 70 - 110 7 - 11 60 - 95
Cylinder cover Flanged bolt M 5* 30 - 45 3.0 - 4.5 25 - 40
Button bolt M 5* 20 - 30 2 - 3 17 - 25
Engine Crankcase M 5 70 - 110 7 - 11 60 - 95
Cylinder M 5 70 - 110 7 - 11 60 - 95
Muffler M 5 60 - 80 6 - 8 55 - 70
Exhaust guide M 4 14 - 28 1.4 - 2.8 12 - 24
Muffler cover M 5* 30 - 45 3.0 - 4.5 25 - 40
Top guard M 5* 20 - 40 2 - 4 20 - 32
Other Cutter fastener LM 10 280 - 320 28 - 32 245 - 280
Regular bolt, nut and screw M 3 6 -10 0.6 - 1 5 - 9
M 4 15 -25 1.5 - 2.5 13 - 22
M 5 25 -45 2.5 - 4.5 22 - 40
M 6 45 -75 4.5 - 7.5 40 - 65
M 8 110 -150 11 - 15 95 - 130
LM: Left-hand thread. * Apply thread locking sealant. (See below)
** The torque differences among four bolts should not exceed 20 kgf•cm (2N•m, 17in•lbf) on one cylinder or crankcase
1-4 Special repairing materials
Material Location Remarks
Grease Drive shaft
Gear case
Lithium based grease or ECHO LUBE
TM
Rewind spring
Starter center post
Oil seal inner lips
Thread locking Starter case
Loctite #675 or equivalent
sealant Fuel tank
Ignition coil Loctite #242, ThreeBond #1324 or equivalent
Fan cover
Top guard
Stand Loctite #222, Three Bond #1342 or equivalent
Muffler cover
Cylinder cover
