SERVICE INFORMATION
SRM-265ES
9
3 SERVICE HINT
3-1 Reassembling 2 Nord-lock washers on Muffler
1. 2 Nord-lock washers (A) are installed to prevent
muffler nuts (B) from loosening. There is a chance
for the 2 Nord-lock washers (A) to drop separately
when loosening muffler nut (B).
2. If 2 Nord-lock washers (A) are separated,
reassemble 2 Nord-lock washers (A) as shown on
Fig.1
NOTE : 2 Nord-lock washers (A) are bonded for
spare parts(No. 92280-05000).
(A)
(A)
(Fig 1)
(B)
