wheeled trimmer
12
Section
7
SPECIFICATIONS
MODEL
WT190SE WT160S WT160T WT190 WT190S WT190T
ENGINE
B & S
Quantam
Honda OHC Honda OHC
B & S
Quantum
B & S
Quantum
B & S
Quantum
ENGINE
CAPACITY
190cc 160cc 160cc 190cc 190cc 190cc
DRIVE 3-Spd Self-Prop 3-Spd Self-Prop Push Push 3-Spd Self-Prop Push
CUTTING
WIDTH
24" 24" 24" 24" 24" 24"
WHEEL SUP-
PORT
Ball Bearings Ball Bearings Ball Bearings Ball Bearings Ball Bearings Ball Bearings
CUTTING
HEIGHT
1-7/8" & 2-3/4" 1-7/8" & 2-3/4" 1-7/8" & 2-3/4" 1-7/8" & 2-3/4" 1-7/8" & 2-3/4" 1-7/8" & 2-3/4"
NYLON CUTTING
STRING
.155 Heavy
Duty
.130 Optional
.155 Heavy
Duty
.130 Optional
.155 Heavy
Duty
.130 Optional
.155 Heavy
Duty
.130 Optional
.155 Heavy
Duty
.130 Optional
.155 Heavy
Duty
.130 Optional
PARALLEL
TRIMMING
Manual Manual Standard Manual Manual Standard
TILT HEAD No No Mechanical No No Mechanical
WEIGHT 84 lbs. 86 lbs. 82 lbs. 77 lbs. 85 lbs. 77 lbs.
OVERALL
LENGTH
50" 50" 50" 50" 50" 50"
OVERALL
HEIGHT
38" 38" 38" 38" 38" 38"
OVERALL
WIDTH
21" 21" 21" 21" 21" 21"
FRAME
MATERIAL
Solid steel Solid steel Solid steel Solid steel Solid steel Solid steel
HANDLEBARS
AND BAIL
Powder baked
paint with
foam grip
Powder baked
paint with
foam grip
Powder baked
paint with
foam grip
Powder baked
paint with
foam grip
Powder baked
paint with
foam grip
Powder baked
paint with
foam grip
START Electric Recoil Recoil Recoil Recoil Recoil
FUEL CAPACITY 1.5 qt. 1.2 qt. 1.2 qt. 1.5 qt. 1.5 qt, 1.5 qt.
UNIT
WARRANTY
2 yr. consumer;
1 yr.
commercial.
2 yr. consumer;
1 yr.
commercial.
2 yr. consumer;
1 yr.
commercial.
2 yr. consumer;
1 yr.
commercial.
2 yr. consumer;
1 yr.
commercial.
2 yr. consumer;
1 yr.
commercial.
ENGINE
WARRANTY
See engine
owners manual.
See engine
owners manual.
See engine
owners manual.
See engine
owners manual.
See engine
owners manual.
See engine
owners manual.
CONTROL
VIBRATION
LEVEL
<2.5 m/s2 <2.5 m/s2 <2.5 m/s2 <2.5 m/s2 <2.5 m/s2 <2.5 m/s2
NOISE LEVEL 101 dB 98 dB 98 dB 101 dB 101 dB 101 dB
7.1 SIZE SPECIFICATIONS
