wheeled trimmer
5
ENGLISH
ASSEMBLY
2.3 FILL THE FUEL TANK
Use only those types of fuels that are recommended in
your engine owner’s manual.
To add fuel:
Stop engine, wait for all parts to stop moving and 1.
disconnect spark plug wire. Remove key from key
switch. Allow the engine and muffler to cool for at least
three minutes.
Clean area around fuel fill cap and remove cap.2.
Using a clean funnel, fill fuel tank to 1/2” below bottom 3.
of filler neck to provide space for any fuel expansion.
Install fuel fill cap securely and wipe up any spilled
gasoline.
Gasoline and diesel fuels are highly ammable
and their vapors are explosive. To prevent
personal injury or property damage:
Store fuel only in approved containers, in well
ventilated, unoccupied buildings, away from
sparks or ames. A container with a capacity of 2 gallons
or less with a pouring spout is recommended. Do not ll
the fuel tank while the engine is hot or running, since
spilled fuel could ignite if it comes in contact with hot
parts or sparks from ignition. Do not start the engine
near spilled fuel. Never use fuel as a cleaning agent.
DO NOT MIX OIL WITH FUEL.
WARNING
2.2 ADD OIL
Check the oil level and, if needed, ll the engine crankcase with the type and amount of oil specied in the engine
owner’s manual.
Adjust the handlebar height by rotating the handlebar until the top hole on the handlebar is aligned with a corresponding 4.
hole on the handlebar support channel and attach using two 5/16" x 1" bolts, washers and nuts. DO NOT TIGHTEN
BOLTS AT THIS TIME.
Tighten the bolts securing the manual container to the handlebar. 5.
Tighten all remaining bolts.6.
Use the two ties provided in the owner's kit to tie the wires to the handlebar.7.
