Installation Guide
7
tel - 1-800-477-2267
email - support@aampglobal.com
Illustrations are typical and may not match exact vehicle detail
FCTP-MB1903
Sprinter Tow Package
Step 6
Release the radio brain by removing the four T20 Torx bolts,
one at each corner, that were exposed by removing the dash
panel. Rest the radio brain on the lower dash.
Step 8
Remove the sub dash panel by tilting the top toward the rear
of the vehicle and lifting out of the dash.
Step 7
Remove the sub dash panel by removing the four T20 Torx
bolts, one at each corner, that were exposed by removing
the radio brain.
