Ecler DPA2000 - Technical Characteristics

31
8. TECHNICAL CHARACTERISTICS 8. CARACTERÍSTICAS TÉCNICAS
8. CARACTERISTIQUES TECHNIQUES 8. TECHNISCHE DATEN
DPA600 DPA1000 DPA1400 DPA2000
POWER 20-20kHz 1% THD
2 Stereo 410 WRMS 682 WRMS 990 WRMS 1420 WRMS
4 Stereo 275 WRMS 440 WRMS 635 WRMS 940 WRMS
8 Stereo 180 WRMS 275 WRMS 395 WRMS 550 WRMS
8 Bridged 550 WRMS 882 WRMS 1270 WRMS 1880 WRMS
Peak Power 2/1kHz 0.98Kw 1.5Kw 2Kw 2.95Kw
Frequency response (-1dB) 7Hz-50kHz 7Hz-50kHz 7Hz-50kHz 6Hz-50kHz
High pass filter (-3dB) 25Hz/Butt./18dB/oct.
THD+Noise @ 1kHz Full Pwr. <0.03% <0.03% <0.03% <0.07%
Imd. Dist. 50Hz & 7kHz, 4:1 <0.05% <0.08% <0.08% <0.08%
TIM 100 <0.01% <0.01% <0.01% <0.01%
S+N/N 20Hz-20kHz @ 1W/4 >85dB >85dB >85dB >85dB
Damping factor 1kHz @ 8 >300 >300 >300 >300
Slew Rate ±60V/µs ±65V/µs ±75V/µs ±80Vµs
Channel crosstalk @ 1kHz >75dB >75dB >75dB >75dB
Input connector XLR3 balanced
Input CMRR/ref. Max. PWR) >60dB @ 1kHz
Input Sensitivity / Impedance 0dBV/>22k
Signal present indicator -40dB
Output connectors Speakon
Clip indicators -1.5dB real clip
Anticlip limiter 1% & 5% aprox.
Mains Depending on your country. See characteristics in the back of the unit.
Power consumption:
(pink noise, 1/8 power @ 4ohm) 479VA 746VA 1023VA 1426VA
(pink noise, 1/3 power @ 4ohm) 728VA 1122VA 1548VA 2160VA
(max. Out) 830VA 1250VA 1720VA 3115VA
Dimensions
Panel 482.6x88 mm
Depth 420 mm 420 mm 420 mm 470 mm
Weight 12.7kg 16.6kg 19.3kg 22.7kg
