Eclipse 5600 - Page 11

11
Eclipse Veri-Flame Instruction Manual 818 -6/06
Dimensions (continued)
171mm
(6-3/4")
Veri-Flame/Modulating Model with Base Model Number 5602-40
1 2 3 4 5 6 7 8 A D 11 12 1310S2 S1
116mm
(4-9/16")
40mm
(1-9/16")
5mm (3/16")10mm (3/8")
25mm
(1")
213mm (8-3/8")
24mm
(15/16")
Remote Display Model Number 5602-DBP
Contrast
Adjustment
Screw
Ground
Screw
Wiring
Terminals (2)
54mm
(2-1/8")
102mm
(4") Square
89mm
(3-1/2")
Square
Mounting
Bracket &
Screw (2)
= Alternate Mounting Locations
*
*
*
