PARAMETER DESCRIPTION
Supply • Series 5602 & 5605: 120 VAC (
+
10%,
-
15%), 50/60 Hz standard.
Series 5603: 240 VAC (
+
10%,
-
15%), 50/60 Hz standard.
Internal power consumption: 12 VA (excluding external connected loads).
Temperature Ranges
Unit Model Nos. Temperature Range
Veri-Flame All Models -40° to +60°C (-40° to +140°F)
90° U.V. Scanner 5600-90A -20° to +60°C (0° to 140°F)
U.V. Scanner 5600-91 -20° to +125°C (0° to +257°F)
NEMA4 UV Scanner 5600-91N4
-20° to +125°C (0° to +257°F)
UV/IR Scanner 5600-92SC -20° to +80°C (0° to +176°F)
Self-Check U.V. 5602-91 -20° to +60°C (0° to +140°F)
Remote Display 5602DBP 0° to 50°C (32° to 122°F)
Flame Failure Response 3 seconds ±0.5 seconds.
Trial For Ignition (TFI)
No Purge & Purge Models:
Series 5602 & 5603: 5 or 10 seconds selectable.
Series 5605: 10 or 15 seconds selectable.
Modulating Model: 5 or 10 seconds selectable
Pilot Interrupt (if selected) 10 seconds.
Purge Time Selectable from 0-225 seconds in 15 second increments.
Output Ratings
for
120 VAC
(maximum total connected
Gas Valve
3, 5 175VA, 1/10 HP 10 amps
load not to exceed 15 amps)*
Ignition
4 375 VA 10 amps
Motor or Contactor
8
470 VA, 1/2 HP
16 amps
Output Ratings
for
240 VAC
Function
Terminals
(maximum total connected
Valves, Ignition
3, 4, 5,
5 amps
load not to exceed 15 amps)*
Motors or Contactor
8
5 amps
Alarm
10, 11, 12, 13 5 amps
Control Signal
A, 10, 11, 12, 13
175VA
10 amps
Relay Contact Rating
Resistive Load
Control
16 amps
A
Relay Contact Rating
Resistive Load
UL, CSA
Inductive Load
Terminals
Function
be less than 10 timesthe rating. The inrush current must not be applied more than once every 15 seconds.
