E C O P H Y S I C S Operating Guide
CLD 780 TR / July 2000 57
4. “Reset CLD“: All the analyzer parameters will be reset to the factory
default values.
If “YES“ is pressed, window (29) appears.
Return with “NO“ to window (28).
Return to measurement function with “MEAS“.
(29) “Master Reset Ready“-window
Security step that questions whether or not a master reset should be exe-
cuted.
– With key YES: master reset will be executed.
– With key NO: return to window (28)
After a “Master Reset“ is performed the Error Code E-01 “Setup and Cal
Data Lost“ appears. To remove this error, perform the warm start proce-
dure by pressing “SYS“, “YES“ and “MEAS“.
Caution: When a Master Reset is performed
– the calibration values
– all user selected settings will be erased.
