SDi Decades Extreme Service Manual www.ecoer.com
May. 2023Manufacturer reserves the right to change specifications or designs without notice.
Note: Remove the panel plate (refer to 10.2.1 Panel Plate) before disassembling fan.
Procedure
Illustration
1) Remove the nut securing the
fan with a spanner (see ODU_
FAN_1&2).
2) Remove the fan.
ODU_FAN_1
ODU_FAN_2
10.2.3 Fan Assembly
Note: This section is for reference only. Actual unit appearance may vary.
