3) Remove the hex nuts and washers
securing the compressor, located on the
bottom plate (see ODU_COMP_3).
4) Heat up the brazed parts and then
remove the the discharge pipe and the
suction pipe (see ODU_COMP_4).
5) Lift the compressor from the base
pan assembly with pliers.
