5
www.ecoflamburners.com
420010372804
EN
IT
FR
ES
RU
Overview  Dimensions / Panoramica  Dimensioni / Vue d'ensemble  Dimensions / Descripción  Dimensiones / Обзор  Размеры
X
Y
Z
Packaging
MAX GAS 40
GAS TRAIN DIMENSIONS:
refer to GT manual
Ø r
RrSr
d..°
Ø a
Ø b
Ø c
125
153
M
MAX GAS 70-105-120
d..°
Ø a
Ø b
Ø c
125
M
MAX GAS 40
CB
A
E
D-D1
F
G
M
I
L
M
ax
G
as
70P
-
120P
N P
O
MAX GAS 70 - 105 - 120
A
BC
D-D1 E
M
I
L
G
F
N
O
Model
A
B C
D D1
E F G
I L M
N O P
MAX GAS 40 P 288 143
145 85 185
153 89 160
92/107
92/107 M8 54 73 -
MAX GAS 70 P 303 155
148 85 185
204 89 160
100/120
100/120 M8 52 71 82
MAX GAS 105 P 317 169
148 140 220
204 89 160
100/120
100/120 M8 52 71 82
MAX GAS 120 P 317 169
148 160 240
204 98 160
100/120
100/120 M8 52 71 82
Model Ø a Ø b
Ø c d°..
MAX GAS 40 P
100 130
150
45°
MAX GAS 70 P
110 140
170
45°
MAX GAS 105 P
110 140
170
45°
MAX GAS 120 P
110 140
170
45°
Model
X
Y
Z Kg
MAX GAS 40 P 380 400
290
8,5
MAX GAS 70 P 385 490
270
9
MAX GAS 105 P
385
490
270
9,5
MAX GAS 120 P
385
490
270
9,5
Boiler plate drilling
D = Short head D1 = Long head
