Contents  Burner description
A1 E-BCU Gas control unit
F6 Air pressure switch
M1 Electric motor
T1 Ignition transformer
Y Graduated rod for head adjustment
3 Air regulation in the burner head
5 Housing
8 Blast tube
10 Wieland socket
15 Burner flange
16 Reset key
103B Air regulation
113 Air intake
A1
8
113
10
5
3
103B
Y
M1
F6
16
MAX GAS 40 LN P TC TW
MAX GAS Gas
NAME
MAX GAS 40 40 kW
MODEL
LN L N Class 3 GAS EN676 (<80 mg/kWh)
EMISSION
P 1 stage
OPERATION TYPE
TC Short head
TL Long head
OPERATION TYPE
Natural gas
LPG LPG
CONTROL BOX
TW Ariston E-BCU
FUEL
Technical label
Tampering, removal or absence of plate
burner or anything that not allow the
secure identification of the burner make
difficult for any installation and
maintenance activity.
Notes for the operator
The system should be inspected by a
specialist at least once a year. It is
advisable to take out a maintenance
contract to guarantee regular servicing.
Technical label
Tampering, removal or absence of plate
burner or anything that not allow the
secure identification of the burner make
difficult for any installation and
maintenance activity.
Notes for the operator
The system should be inspected by a
specialist at least once a year. It is
advisable to take out a maintenance
contract to guarantee regular servicing.
Scope of delivery
The burner is delivered in a modular system
of packagings i.e. separate set/box:
BBCH: Burner Body with Combustion Head
with flange.
- 1 bag including :
- multilanguage technical manual.
- wieland plug.
- screws, nuts and washer.
GT: separate Gas Train
KIT & ACS are managed and delivered separately
KIT & ACS delivered separately
For any other use, the authorization of Ecoflam is required.
WARNING
15
