Ecoflam Multicalor 70 - PARAMETERIZATION; PROBE CONNECTION DIAGRAMS

pag.30
B LB 1371 Multicalor 45 ÷ 140
PROBE CONNECTION DIAGRAMS
SPH
60
80
100
0
20
40
SPL
120
140
160
20
15 10
5
0
-20
-15-10-5
17.5
12.5 7.5
2.5
-2.5
-17.5-12.5-7.5
0.2
0.4
0.6
0.8
1
1.2
1.4
1.6
1.8
2
2.2
2.4
2.6
2.8
3
3.2
3.4
3.6
3.8
4
External temperature (iC)
Heating curve gradient (H)
PARAMETERIZATION
Boiler temperature set point (iC)
Cod.
S704
Cod. S721
Cod.
S731
S731/1
S731/2
S731/3
S731/4
Cod.
S720/1
Connection for probe
QAE2..(passive probe)
Water probe
Configuration code
C111 = 9XXX
Connection for probe
FT-TP/..(passive probe)
(Degusa probe)
Configuration code
C111 = 5XXX
Connection for probe
QBE620-P..(active probes)
Configuration code
C111 = GXXX
S731 - 0…4 bar / 0…400 kPa
QBE620-P4
S731/1 - 0…10 bar / 0…1 MPa
QBE620-P10
S731/2 - 0…16 bar / 0…1.6 Mpa
QBE620-P16
S731/3 - 0…25 bar / 0…2.5 MPa
QBE620-P25
S731/4 - 0…40 bar / 0…4 MPa
QBE620-P40
Connection for probe
QAC22 (passive probe)
Configuration code
C111 = XX3X
C112 = XX1X
1234
RWF 40
B
M
G1+ M1
QAE22A
1234
RWF 40
B
M
B9 M9
QAC2..
1234
RWF 40
GL
M
G+ M1
OBE620-P..
U1
G-
U1
