|11
L
· Live line
N
· Neutral wire
PE
· Ground wire
L
N
PE
2
2
1
1
3
3
×1
×1
A6
A7
70-75mm
70-75mm
12-16mm
12-16mm
Connecting
BACKUP Cables
• Before installing, operating, and maintaining the equipment, always disconnect it from all power.
• Do not connect the BACKUP connector to the GRID terminal of the inverter.
• It is not recommended to connect loads with high starting power to BACKUP terminal, such as
vacuum cleaner, air conditioner, etc.
• RCD with rated residual operating current of 100 mA (AC-GRID) and 30mA (AC-BACKUP) would
be recommended if there is additional protection by RCD shall be provided for local electrical
installation, while the use of an RCD with lower rated residual operating current is also permitted
if it is required by the specific local electrical codes.
6
6
4
4
N
N
L
L
PE
PE
PH2
PH2
1.2 N.M
1.2 N.M
5
5
GRID Terminal
GRID Terminal
GRID Terminal
GRID Terminal
Remove
protective cap with a
screwdriver
Remove
protective cap with a
screwdriver
GRID Connector
GRID Connector
PH2
PH2
1.2 N.M
1.2 N.M
A9
A7
A8
A9
To Next Page
