CPU Serial number CPU Serial number, also written in the label of the CPU.
It varies depending on
CPU.
Software version CPU Software version
It varies depending on
the CPU.
Fuel Pellet
Pellet, olive pit, almond
shell.
Water pressure
Water pressure in the hydraulic circuit (only water
models).
Water pressure in bars
5.5. OPERATING MODES.
To access this menu the stove must be turned off and showing no alarm (status 0).
The characteristics of the operating modes are set out below.
WATER (BOILER /HYDROSTOVE)
POWER
• Default configuration.
• Manual power management.
Power level modifiable from keyboard, web or
calendar set.
9 power levels, 9 being the maximum level.
Monozone; Room T. = 21 ° C; Heating drive = 65
° C; T. Stand-by = 82 °C
• Manual power management.
Power level modifiable from keyboard, web or
calendar set. 9 power levels, 9 being the
maximum level.
If the demand of the control
probe, thermostat or THT) or the water supply
has been satisfied, it will reduce power to the
minimum level.
• Room temp. regulation range between 12 ° C
and 40 ° C.
• Possibility of managing on and off, according to:
– Control terminals.
TEMPERATURE
• Automatic power management.
According to demand of the control terminal
(room probe, thermostat or THT):
– Instantaneous power level.
– On and off (configurable).
• Room temperature regulation range between
12 ° C and 40 °C.
• Automatic power management.
According to the supply temperature and the
demand of the control terminal (room probe,
thermostat or THT).
• Possibility of managing on and off, according to:
– Control terminals.
– Buffer sensors.
• Ambient regulation range between 12 ° C and
To select the temperature mode, set the operation mode.
Operating mode selection.
Password. (Technical assistance)
Drawing 36
Power
Temperature
User:
Password:
SETTINGS SEND
MODE
LOGIN
