Universal Support Brackets Installation
Universal Mid Support Brackets are a non-standard item and only used in heavy load conditions with light-duty
panels. The design team at Ecolibrium Solar will indicate use when required.
Installing Lower Universal Mid-Support
ADDENDUM B
Install on low side of module at
the module midpoint.
To install, pull bracket onto the midpoint of module return flange until upright locking tab pops up on the
frame’s edge. This indicates the bracket is fully engaged.
