ECD2800 / ECD2600
25 / 47
Negative dynamic range setting does not influence output range of analogue output. If there
is a value −0.8 AU (neg. dynamic range = HIGHER) on the display, on analogue output will be
minimal value for selected range.
6.4.4.1. Range
Here can be set output voltage range in four levels (1, 2, 3 and 4 V)
6.4.4.2. Offset
Offset of analogue output can be set in range 0 – 1 V (default value is 0 mV)
6.4.4.3. Conversion Ratio
Conversion ratio of output voltage to AU can be set in six ranges 0.2/0.5/1/2/5/10 V = 1 AU
(default value is 1 V/AU).
6.5. Info
6.5.1. Device
Displays unit NAME, its S/N - serial number and TIME - total operating time.
6.5.2. Boards
Here can be selected board we need information about
6.5.2.1. Main Board
BN – board name, HW – board version, FW – firmware version, UN – board identification
number.
6.5.2.2. Display Board
BN – board name, HW – board version, FW – firmware version, UN – board identification
number.
6.5.2.3. Power Board
BN – board name, HW – board version, FW – firmware version.
6.5.2.4. XPORT Module
Ethernet module..
BN – board name, HW – board version, FW – firmware version, UN – board identification
number.
6.5.3. Ethernet
Actual setting of Ethernet. IP – IP address, MASK – subnet mask, GATE – default gateway,
MAC – unique hardware address.
6.5.4. User text
Default is empty. The user may input supplementary information about the detector when
using software. E.g. location in the laboratory. USER TEXT is then a part of the protocol.
