ECD2800 / ECD2600
26 / 47
6.5.5. Lamps
Here can be selected lamp we need information about.
6.5.5.1. Deuterium (D2)
Displays: NAME - lamp name, IDF- identification number, TIME- operating hours and CHIP-
service statistic data from lamp chip.
6.5.5.2. Tungsten (W)
Displays: NAME- lamp name and TIME- operating hours
6.5.6. Cell
Displays NAME- cell name and IDF- identification number
6.6. Diagnostic
6.6.1. Errors
If a serious problem occurs, display shows
symbol E with a number of errors in brackets.
Meaning of these errors is described in this
menu, which you can enter fast by pressing key
ENTER.
If a problem occurs, which does not obstruct
further operation, display shows symbol W with
a number, which means number of warnings.
Meaning of these warmings is described in this
menu, which you can enter fast by pressing key
ENTER.
6.6.3. Power
6.6.3.1. Main
To control values of main supply voltage:
Positive main power supply
