ECD2800 / ECD2600
27 / 47
Name
Description
Nominal [V]
Min [V]
Max [V]
VAP
Positive Analog power supply
+11.60
+11.00
+12.00
VAN
Negative Analog power supply
-11.80
-11.20
-12.20
VCC
Positive Digital power supply
+5.10
+4.90
+5.30
VDD
Positive Low Digital power supply
+3.30
+3.20
+3.40
VLP
Positive Low Analog power supply
+4.80
+4.70
+4.90
VLN
Negative Low Analog power supply
-0.40
+0.35
-0.45
6.6.3.2. Lamps
For control of main supply voltage and current values of D2 (deuterium lamp) and
W (tungsten lamp)
Name
Description
Nominal
Min
Max
VHT
D2 Heating voltage (D2 OFF)
0.00V
D2 Heating voltage (D2 ON)
1.55 V
1.42 V
1.68 V
D2 Heating voltage (D2 preheating)
3.48 V
3.22 V
3.72 V
VAD
D2 Anode voltage (D2 OFF)
29.50 V
D2 Anode voltage (D2 ON)
68.00 V
62.00 V
78.00 V
D2 Anode voltage (D2 IGNITION)
500.00 V
IAD
D2 Anode current (D2 OFF)
0.000 A
D2 Anode current (D2 ON)
0.270 A
0.260 A
0.280 A
VBL
W voltage (W OFF)
0.00 V
W voltage (W ON)
11.00 V
10.50 V
11.80 V
IBL
W current (W OFF)
0.000 A
W current (W ON)
0.812 A
0.780 A
0.840 A
VFA
SMALL FAN voltage (both lamps OFF)
0.00 V
SMALL FAN voltage (any lamp ON)
18.80 V
18.00 V
19.60 V
IFA
SMALL FAN current (both lamps OFF)
0.000 A
SMALL FAN current (any lamp ON)
0.025 A
0.020 A
0.030 A
6.6.4. Cooling
Shows temperature of illuminator TEMP, rotation speed of fans FAN1 and FAN2 (rpm) and
their voltage (V) and chosen mode of illuminator temperature regulation MODE. Stability of zero
line (drift) is dependent on setting of temperature regulation.
6.6.5. Interface
Shows analogue and digital interface status of IO INTERFACE:
Voltage on analogue input AIN (V), status of digital inputs DIN1 and DIN2 and digital
output mode DOUT set according to chapter Menu/IO Config/Interface /Digital output switch.
6.6.6. Cell Temp
Inactive.
6.6.7. Opti Calib
Here you can find data from optical unit calibration, where line 486 shows control point at
486 nm and last item R shows real wavelength, where was found maximum of this hydrogen
