5. PROCEDURE FOR INSTALLING AN FU CABINET OR FK CABINET SYSTEM
The mulblock performs a bypass funcon, is equipped with a sampler and has 2 modes
of operaon:
Open posion — Supply via
soener/limescale protecon
system: handwheel in UPPER
posion (stop)
Bypass posion — Supply via
soener/limescale protecon
system: handwheel in LOWER
posion (stop)
Place the ng of the overow hose (1) at
least 20 mm below the height of the safety
overow of the domesc water soening
system. Fix vercally with the bracket
(H). Connect the ush water hose with a
downward slope to the ng (2) and insert to
a depth of approx. 90 mm.
Connect the overow hose from the brine
tank to the ng (1) and x with a hose
clamp.
The ush water hose and the overow hose
mustn`t be connected and mustn`t have
narrowing in the cross secon.
