MANUAL FOR ECOSOFT PINK SOFTENERS
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2024
5. PROCEDURE FOR INSTALLING SOFTENERS
The mulblock performs a bypass funcon, is equipped with a sampler and has 2 modes of
operaon:
Open posion — Supply via soener/limescale
protecon system: handwheel in UPPER
posion (stop)
Place the ng of the overow hose (1) at least
20 mm below the height of the safety overow
of the domesc water soening system. Fix
vercally with the bracket (H).
Connect the ush water hose with a downward
slope to the ng (2) and insert to a depth of
approx 90 mm.
Connect the overow hose from the brine tank
to the ng (1) and x with a hose clamp.
The ush water hose and the overow hose
mustn`t be connected and mustn`t have
narrowing in the cross secon.
Bypass posion — Supply via soener/
limescale protecon system: handwheel in
LOWER posion (stop)
For ushing the
household water
system
Overow hose of
a household water
soening system
For connecon to
the drainage system
90°90°
H
2
1
DN 40
приблизно 90 мм
