5. PROCEDURE FOR INSTALLING SOFTENERS
7. Remove the front panel by pulling the locking tabs on the le and right side. Run the power
cord through the cord guide in the control valve’s backplate and connect it to 12 VAC socket on
the circuit board. Plug the power supply in the mains to power up the system.
8. Start manual regeneraon of the system. Scroll regeneraon to backwash if it isn’t the 1st step
of the sequence. When the control valve starts the backwash, turn on mains water supply slightly
at rst. Air will be displaced from the system via drain line while the pressure tank is being lled
with water. When the tank is full, water will start owing down the drain line. At this point, fully
open mains water supply.
Let the system complete regeneraon, then perform one more manual regeneraon.
5.1 OPTIONAL EQUIPMENT
Soening systems can be addionally equipped with a Clack or Mulblock bypass valve. The Clack
bypass valve is aached directly to the inlet and puried water pipes and has 4 operang modes,
listed below:
NORMAL OPERАTION
DIAGNOSTIC MODE
BYPASS OPERАTION
SHUT OFF MODE
“TREATED”
WATER EXIST
SUPPLY
WATER EXIST
SUPPLY
WATER EXIST
NO WATER
EXIST
SUPPLY WATER
ENTERS
SUPPLY WATER
ENTERS
SUPPLY WATER
ENTERS
SUPPLY WATER IS SHUT
OFF FROM THE HOUSE
AND THE VALVE
